Wireless Central Monitoring System 15 inch Multi Parameter Patient Monitor
| Specification |
| Parameters | ECG, PR,SPO2,NIBP,TEMP,RESP |
| Apply For | Adult/Pediatric/Neonatal |
| Application | Medicine/Surgery/Operating Room/ICU/CCU |
| Display | 15 inch color TFT screen |
| Operating Environment |
| Temperature: | 0 ~ 40 ℃, 5 ~ 40 °C with CO₂ |
| Humidity: | 15% - 90 % |
| Pressure: | 86.0 kPa ~ 106.0kPa |
| Transport and Storage environment : |
| Temperature: | -20 ~ 55 ℃ |
| Humidity: | 15% - 90 % (no coagulation) |
| Pressure: | 86.0 kPa~ 106.0kPa |
| Power Requirements |
| AC: | 100 ~ 240V, 50Hz/60Hz |
| DC: | Built-in rechargeable battery |
| Battery: | 2200 mAh 14.8V rechargeable Lithium battery;
2h operating after full charge;
5min operating after low battery alarm; |
| Date Storage |
| Trend diagram/table: | 720h |
| NIBP review: | 10000 events |
| Wave review: | 12h |
| Alarm review: | 200 alarm events |
| Analysis: | Support drug concentration titration analysis |
| ECG |
| 5 Leads: | RA, LA, LL, RL, V |
| Lead mode: | I, Ⅱ, Ⅲ, AVR, AVL, AVF, V |
| Gain: | × 1.25mm/mV,2.5mm/mV,
5.0mm/mV,10mm/mV,
20mm/mV (error ≤ 5%) |
| Sweep speed: | 6.25mm/s,12.5mm/s,25mm/s,
50mm/s (error ≤ ± 10%) |
| Bandwidth: | Surgery 1 ~ 25 Hz,
Monitor 0.5 ~ 40 Hz,
Diagnostic 0.05 ~ 130 Hz |
| Sensitivity: | >200 u V P-P |
| CMRR: | ≥ 112dB |
| Differential Input Impedance: | >5M |
| ohm Electrode Offset Potential: | ±300mV |
| Polarization Voltage: | ≥ ± 500mV |
| Input Impedance: | ≥ 5 M |
| Calibration Voltage: | 1mV ± 5% |
| ST Segment |
| ST Segment Range: | -2.0mV ~ +2.0mV |
| Accuracy: | 0.02mV |
| Optional accessories | 1.Trolley bracket |
| 2.Hanging bracket |
| 3.Monitor recorder |
| 4.Vehicle-mounted power supply |
Product brief
- Plug -in rechargeable battery, AC/DC available
- Parameters include ECG, Respiration, NIBP, dual temperature,SpO2, pulse rate, dual IBP, CO₂
- Adopt digital SpO2 technology, anti-motion and anti-ambient light interference, and measurement can be performed under the circumstance of weak filling.
- ECG monitoring include arrhythmia analysis, ST calculation and Pace analysis
- Protected against defibrillation, ESU and myoelectric artifact
- NIBP over pressure protection
- Human voice alarm helps the user to identify the source of alarms
- Embedded network can connect to central monitor server
- Maximum 720 hours trend review, 1000 NIBP review, 2 hours full wave review and 200 alarm event review
- Multi-display:standard,large font,trend coexis
- Support Central Monitoring System
- 15'' TFT color LCD, resolution: 800*600
- Multi~lead ECG waveforms display in phase.
- All-round monitor for adult, pediatric and neonate.
Packing
Packing terms: Anti-collision film+ Carton box
Carton box dimension: 41*29.5*38cm
Gross weight: 5.85kg
Shipping:
Air shipping or Express courier is recommended if the order quantity was less than 20 units. It usually takes around 7 days to reach the destination. By ocean shipping, it normally takes 20-40 days depending on the destination port.
FAQ
1.who are we?
We are based in Hunan, China, start from 1997,sell to Domestic Market(50.00%),Southeast Asia(15.00%),Africa(10.00%),Central America(10.00%),Mid East(8.00%),South Asia(7.00%). There are total about 11-50 people in our office.
2.why should you buy from us not from other suppliers?
Hunan Rainbow Technology Co,Ltd is a professional manufacturer and wholesaler in monitor with 19-year experience. In order to meets the marketing demand, our company cooperate with the America RMS Company to release a serials of PM-9000 parameters monitor.
3.what can you buy from us?
Multi parameter Patient Monitor,ECG Machine,Infusion Pump,Syringe Pump,Nutritional Pump
4.what services can we provide?
Accepted Delivery Terms: FOB,EXW,Express Delivery；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T;
Language Spoken:English,Chinese
